Renault 70-12 LB
|
|
| Production | |
| Manufacturer | Renault |
| Utility tractor | |
| Variants | |
| 70-12 LB | 2WD |
| Renault 70-12 LB Engine | |
| Deutz 3.8L 4-cyl diesel | |
| Fuel tank | 16.4 gal 62.1 L |
 Engine details ... | |
| Renault 70-12 LB Transmission | |
| 12-speed Four gears in three ranges with mechanical shuttle. | |
 Transmission details ... |
| Renault 70-12 LB Power | |
| Engine | 65.7 hp 49.0 kW |
| Mechanical | |
| Two-wheel drive | |
| Final drives | planetary |
| Differential lock | mechanical rear |
| Power steering | |
| Wet disc brakes | |
| Four-post ROPS. Cab optional. | |
| Photos | |
| No photos of the Renault 70-12 LB are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pressure | 2611 psi 180.0 bar |
| Valves | 1 |
| Pump flow | 9.6 gpm 36.3 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift | 7666 lbs 3477 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 |
| Dimensions & Tires | |
| Weight | 5071 lbs 2300 kg |
| Front tire | 7.50-16 |
| Rear tire | 16.9-28 |
 Full dimensions and tires ... | |
| References | |
 | |
| Baureihe LB published in 1992, by Renault |
