Kubota M8-181


Kubota M8-181 tractor photo
2020 -
M8 Series
Row-Crop tractor
Versatile built
Series:M8-181M8-201
Production
Distributor:Kubota
Manufacturer:Versatile
Type:Row-Crop tractor
Factory:Winnigpeg, Manitoba, Canada
Kubota M8-181 Power
Engine:180 hp
134.2 kW
PTO (claimed):145 hp
108.1 kW
Drawbar (tested):158.26 hp
118.0 kW
PTO (tested):169.73 hp
126.6 kW
power test details ...
Kubota M8-181 Engine
Cummins 6.7L 6-cyl diesel
Fuel tank:99 gal
374.7 L
Exhaust fluid (DEF):9 gal
34.1 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:power
Trailer brakes:hydraulic*Optional
Cab:Cab standard with air-conditioning.
Transmissions:30-speed six-speed power shift
 continuously-variable transmission
Transmission details ...
Photos
No photos of the Kubota M8-181 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:closed-center load sensing
Rear valves:3 to 5
Pump flow:31.7 gpm
120.0 lpm
 42.2 gpm
159.7 lpm *Optional
SCV flow:31.7 gpm
120.0 lpm
Steering flow:11.1 gpm
42.0 lpm
Tractor hitch
Rear Type:III/IIIN
Rear lift (at 24"/610mm):12478 lbs
5660 kg
 15543 lbs
7050 kg *Optional
Front Hitch:IIIN
Front lift:8818 lbs
3999 kg
Power Take-off (PTO)
Rear PTO:independent
Clutch:electro-hydraulic
Rear RPM:540/1000 (1.375)
 1000 (1.75)
Front RPM:1000 (1.375)
Dimensions & Tires
Wheelbase:114 inches
289 cm
Weight:19510 lbs
8849 kg
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
