Tractors > Kubota > M8-181

Kubota M8-181



Kubota M8-181 tractor photo
2020 -
M8 Series
Row-Crop tractor
Versatile built
Series map:
M8-181
M8-201
180.0hp
200.0hp
Production
DistributorKubota
ManufacturerVersatile
Row-Crop tractor
Built in Winnigpeg, Manitoba, Canada
Kubota M8-181 Engine
Cummins 6.7L 6-cyl diesel
Fuel tank99 gal
374.7 L
Exhaust fluid (DEF)9 gal
34.1 L
Engine details ...
Kubota M8-181 Transmissions
30-speed six-speed power shift
continuously-variable transmission
Transmission details ...
Kubota M8-181 Power
Engine180 hp
134.2 kW
PTO (claimed)145 hp
108.1 kW
Drawbar (tested)158.26 hp
118.0 kW
PTO (tested)169.73 hp
126.6 kW
Performance test details ...
Mechanical
Four-wheel drive
Power steering
Trailer brakeshydraulic OptOptional
Cab standard with air-conditioning.
Photos
No photos of the Kubota M8-181 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed-center load sensing
Rear valves3 to 5
Pump flow31.7 gpm
120.0 lpm
 42.2 gpmOptOptional
159.7 lpm
SCV flow31.7 gpm
120.0 lpm
Steering flow11.1 gpm
42.0 lpm
Tractor hitch
Rear TypeIII/IIIN
Rear lift (at 24"/610mm)12478 lbs
5660 kg
 15543 lbsOptOptional
7050 kg
Front HitchIIIN
Front lift8818 lbs
3999 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540/1000 (1.375)
 1000 (1.75)
Front PTO Type1000 (1.375)
Dimensions & Tires
Wheelbase114 inches
289 cm
Weight19510 lbs
8849 kg
Full dimensions and tires ...
Kubota M8-181 attachments
front-end loader
Attachment details ...
Electrical
Groundnegative
Battery volts12
References
M8-181 references literature
M8 Built Right. Built Ready. published in 2021, by Kubota
