Fiat G170
| | 1993 - 2002 |
| G Series | | Row-Crop tractor |
|
Series map:
G170
G190
126.8kw
141.7kw
Note: the Fiat model G170 is the same as the Ford 8670. The following data is from the 8670 listing. |
| Production |
| Manufacturer | Fiat
|
| Row-Crop tractor |
| Built in Winnipeg, Manitoba, Canada |
| Original price was $84,500 in 2000 |
| Fiat G170 Power |
| Engine | 170 hp
126.8 kW
|
| PTO (claimed) | 145 hp
108.1 kW
|
| Drawbar (tested) | 132.1 hp
98.5 kW
|
| PTO (tested) | 167.6 hp
125.0 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Power steering |
| Wet disc brakes |
| Cab standard with air-conditioning. |
| Photos |
| No photos of the Fiat G170 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Capacity |
| Fuel | 110 gal
416.4 L
|
| Hydraulic system | 30.9 gal
117.0 L
|
| Front hubs | 1.7 qts (each)
1.6 L
|
| Front diff. | 13 qts
12.3 L
|
| Hydraulics |
| Type | closed center load sensing
|
| Capacity | 30.9 gal
117.0 L
|
| Pressure | 2750 psi
189.6 bar
|
| Valves | 3
|
| Pump flow | 24 gpm
90.8 lpm
|
| Total flow | 31 gpm
117.3 lpm
|
| | 55 gpm (MegaFlow optional)
208.2 lpm
|
| Tractor hitch |
| Rear Type | III
|
| Rear lift | 10000 lbs
4536 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic wet disc
|
| Rear PTO Type | 540/1000 (1.375)
|
| Engine RPM | 540@1878
|
| | 1000@1903
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 130
|
| Batteries | 2
|
| Battery CCA | 950
|
| Battery volts | 12
|
| References |
 |
| G170, G190, G210, G240 - The Pride of the Field published in 1994, by Fiat |
