Tractors > John Deere > 2036R

John Deere 2036R



John Deere 2036R tractor photo
2016 -
2R Series
Compact Utility tractor
Series map:
2026R
2036R
18.8kw
27.3kw
Production
ManufacturerJohn Deere
Compact Utility tractor
John Deere 2036R Engine
Yanmar 1.5L 3-cyl diesel
Engine details ...
John Deere 2036R Transmission
hydrostatic
Transmission details ...
John Deere 2036R Power
Engine (gross)36.6 hp
27.3 kW
Engine (net)35.9 hp
26.8 kW
PTO (claimed)30 hp
22.4 kW
Mechanical
Four-wheel drive
Final drivesspur gear
Differential lockmechanical rear
Power steering
Wet disc brakes
Two-post folding ROPS. Cab optional.
Photos
No photos of the John Deere 2036R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel8.5 gal
32.2 L
Hydraulic system6.2 gal
23.5 L
Hydraulics
Typeopen center
Capacity6.2 gal
23.5 L
Pressure2500 psi
172.4 bar
Pump flow5.3 gpm
20.1 lpm
Total flow9.3 gpm
35.2 lpm
Steering flow4 gpm
15.1 lpm
Tractor hitch
Rear TypeI
Rear lift (at ends)2086 lbs
946 kg
Rear lift (at 24"/610mm)1356 lbs
615 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchwet disc
Rear PTO Type540 (1.375)
Mid PTOindependent
Mid PTO Type2100
Front PTOindependent OptOptional
Front PTO Type2100
Dimensions & Tires
Wheelbase67.9 inches
172 cm
Weight2425 to 2921 pounds
Front tire7.00-12
Rear tire12.4-16
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps75
Battery CCA500
Battery volts12
References
2036R references literature
Compact Utility Tractors published in 2016, by John Deere
