John Deere 2026R



John Deere 2026R tractor photo
2016 -
2R Series
Compact Utility tractor
Series map:
2026R
2036R
18.8kw
27.3kw
Production
ManufacturerJohn Deere
Compact Utility tractor
John Deere 2026R Engine
Yanmar 1.1L 3-cyl diesel
Engine details ...
John Deere 2026R Transmission
hydrostatic
Transmission details ...
John Deere 2026R Power
Engine (gross)25.2 hp
18.8 kW
Engine (net)23.8 hp
17.7 kW
PTO (claimed)18 hp
13.4 kW
Mechanical
Four-wheel drive
Final drivesspur gear
Differential lockmechanical rear
Power steering
Wet disc brakes
Two-post folding ROPS. Cab optional.
Photos
No photos of the John Deere 2026R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel6.3 gal
23.8 L
Hydraulic system3.8 gal
14.4 L
Hydraulics
Typeopen center
Capacity3.8 gal
14.4 L
Pressure2000 psi
137.9 bar
Pump flow3.7 gpm
14.0 lpm
Total flow7.4 gpm
28.0 lpm
Steering flow3.7 gpm
14.0 lpm
Tractor hitch
Rear TypeI
Rear lift (at ends)1235 lbs
560 kg
Rear lift (at 24"/610mm)882 lbs
400 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchwet disc
Rear PTO Type540 (1.375)
Mid PTOindependent
Mid PTO Type2100
Front PTOindependent OptOptional
Front PTO Type2100
Dimensions & Tires
Wheelbase63 inches
160 cm
Weight1676 to 2028 pounds
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps55
Battery CCA500
Battery volts12
References
2026R references literature
Compact Utility Tractors published in 2016, by John Deere
