Tractors > Deutz-Fahr > 5125

Deutz-Fahr 5125



Deutz-Fahr 5125 tractor photo
2017 -
5 Series
Utility tractor
Series map:
5115
5125
83.0kw
88.0kw
Production
ManufacturerDeutz-Fahr
Utility tractor
Deutz-Fahr 5125 Engine
Deutz 3.6L 4-cyl diesel
Fuel tank35.7 gal
135.1 L
Exhaust fluid (DEF)2.1 gal
7.9 L
Engine details ...
Deutz-Fahr 5125 Transmissions
20-speed partial power shift
30-speed partial power shift
Transmission details ...
Deutz-Fahr 5125 Power
Engine (gross)118 hp
88.0 kW
Engine (max)124.5 hp
92.8 kW
Mechanical
Two- or four-wheel drive
Differential lockelectro-hydraulic front and rear
Power steering
Wet disc brakes
Trailer brakeshydraulic OptOptional
 pneumatic OptOptional
Cab standard with available air-conditioning.
Photos
No photos of the Deutz-Fahr 5125 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pump flow14.5 gpm
54.9 lpm
 15.85 gpmOptOptional
60.0 lpm
 23.8 gpmOptOptional
90.1 lpm
Tractor hitch
Rear TypeII
Rear lift7540 lbs
3420 kg
 10395 lbsOptOptional
4715 kg
 11596 lbsOptOptional
5259 kg
Front lift4630 lbs
2100 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540/540E
 1000/1000E OptOptional
Front PTOindependent OptOptional
Front PTO Type1000
Dimensions & Tires
2WD Wheelbase91.7 inches
232 cm
4WD Wheelbase93.3 inches
236 cm
Weight9921 lbs
4500 kg
Front tire340/85R28
Rear tire420/85R38
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps150
Charging volts12
Battery CCA650
Battery volts12
Battery AH100
References
5125 references literature
5 Series published in 2016, by Deutz-Fahr
