Deutz-Fahr 5115
| | 2017 - |
| 5 Series | | Utility tractor |
|
Series map:
5105
5115
5125
77.0kw
83.0kw
88.0kw
| Production |
| Manufacturer | Deutz-Fahr
|
| Utility tractor |
| Deutz-Fahr 5115 Power |
| Engine (gross) | 111.3 hp
83.0 kW
|
| Engine (max) | 117.3 hp
87.5 kW
|
| Mechanical |
| Four-wheel drive |
| Differential lock | electro-hydraulic front and rear
|
| Power steering |
| Wet disc brakes |
| Trailer brakes | hydraulic OptOptional
|
| | pneumatic OptOptional
|
| Cab standard with available air-conditioning. |
| Photos |
| No photos of the Deutz-Fahr 5115 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| Pump flow | 14.5 gpm
54.9 lpm
|
| | 15.85 gpmOptOptional
60.0 lpm
|
| | 23.8 gpmOptOptional
90.1 lpm
|
| Tractor hitch |
| Rear Type | II
|
| Rear lift | 7540 lbs
3420 kg
|
| | 10395 lbsOptOptional
4715 kg
|
| | 11596 lbsOptOptional
5259 kg
|
| Front lift | 4630 lbs
2100 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic
|
| Rear PTO Type | 540/540E
|
| | 1000/1000E OptOptional
|
| Front PTO | independent OptOptional
|
| Front PTO Type | 1000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 150
|
| Charging volts | 12
|
| Battery CCA | 650
|
| Battery volts | 12
|
| Battery AH | 100
|
| References |
 |
| 5 Series published in 2016, by Deutz-Fahr |
