Hesston 70-66 Orchard
|
|
Series map:
60-66 Orchard
70-66 Orchard
80-66 Orchard
56.7hp*
68.9hp*
77.8hp*
*Estimated engine power for comparison only.
| Production | |
| Distributor | Hesston |
| Manufacturer | Fiat |
| Orchard/Vineyard tractor | |
| Variants | |
| 70-66 | utility 2WD[6073] |
| 70-66DT | utility 4WD[6073] |
| 70-66ORDT | orchard 4WD |
| 70-66HC | high-crop |
| 70-66HCDT | high-crop 4WD |
| Hesston 70-66 Orchard Engine | |
| Fiat 3.6L 4-cyl diesel | |
| Fuel tank | 15.3 gal 57.9 L |
 Engine details ... | |
| Hesston 70-66 Orchard Transmissions | |
| 12-speed syncromesh | |
| 12-speed mechanical shuttle | |
 Transmission details ... |
| Hesston 70-66 Orchard Power | |
| PTO (claimed) | 62 hp 46.2 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Power steering | |
| Mechanical wet disc brakes | |
| Two-post ROPS. |
| Photos | |
| No photos of the Hesston 70-66 Orchard are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2700 psi 186.2 bar |
| Valves | 2 |
| Pump flow | 11 gpm 41.6 lpm |
| Tractor hitch | |
| Rear Type | II/I |
| Control | position and lower-link draft control |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| 2WD Wheelbase | 78.7 inches 199 cm |
| 4WD Wheelbase | 83.1 inches 211 cm |
| Weight | 4850 to 5200 pounds |
| Front tire | 27x9.50-15 |
| Rear tire | 14.9-24 |
 Full dimensions and tires ... | |
| Hesston 70-66 Orchard attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Charging system | alternator |
| Charging amps | 33 |
| Battery volts | 12 |
| References | |
 | |
| Models 60-66, 70-66 & 80-66 Orchard Tractors published in 1988, by Hesston |
