Kubota JB16


No photo available
2006 - 2008
JB Bullstar Series
Sub-Compact Utility tractor
Series:JB14JB16JB18
JB17X
Production
Manufacturer:Kubota
Type:Sub-Compact Utility tractor
Variants
JB16:wheeled
JB16-PC:half-track
Kubota JB16 Power
Engine:16.2 hp
12.1 kW
Kubota JB16 Engine
Kubota 1.0L 3-cyl diesel
Fuel tank:3.7 gal
14.0 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:manual
Steering:power*Optional
Brakes:wet disc
Cab:Two-post ROPS.
Transmission:6-speed
Transmission details ...
Photos
No photos of the Kubota JB16 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear Type:0
Power Take-off (PTO)
Rear PTO:540 (1.375)
Rear RPM:551:2600
 967:2600
Dimensions & Tires
Wheelbase:50 inches
127 cm
Weight:1301 lbs
590 kg
Front tire:5.00-12
Rear tire:8-18
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
