Kubota KL385


Kubota KL385 tractor photo
2008 - 2009
KL Series
Compact Utility tractor
Series map:
KL345
KL385
KL415
25.0kw
27.9kw
30.9kw
Production
ManufacturerKubota
Compact Utility tractor
Variants
KL385standard
KL385Hhigh-speed
Kubota KL385 Engine
Kubota 2.2L 4-cyl diesel
Fuel tank10.6 gal
40.1 L
Engine details ...
Kubota KL385 Power
Engine37.4 hp
27.9 kW
Mechanical
Four-wheel drive
Power steering
Mechanical wet disc brakes
Two-post ROPS. Cab optional.
Photos
No photos of the Kubota KL385 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear TypeI
Power Take-off (PTO)
Rear PTO Type540 (1.375)
Engine RPM540@2600
 762@2600
 944@2600
 1258@2600
 -944@2600
Dimensions & Tires
Wheelbase74.4 inches
188 cm
Weight3351 to 3781 pounds
Front tire8-18
Rear tire12.4-28
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
KL385 references literature
Operator Manual KL (T01850-1920-1)
