Iseki TG293
|
|
| Production | |
| Manufacturer | Iseki |
| Compact Utility tractor | |
| Iseki TG293 Engine | |
| Iseki 1.5L 3-cyl diesel | |
| Fuel tank | 9.25 gal 35.0 L |
 Engine details ... | |
| Iseki TG293 Transmissions | |
| 16-speed mechanical shuttle | |
| 16-speed power shuttle | |
 Transmission details ... |
| Iseki TG293 Power | |
| Engine | 28.6 hp 21.3 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | mechanical rear |
| Power steering | |
| Wet disc brakes | |
| Two-post ROPS. Cab optional. | |
| Photos | |
| No photos of the Iseki TG293 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | 600:2600 |
| 797:2600 | |
| 1094:2600 | |
| 1292:2600 | |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 66.9 inches 169 cm |
| Weight | 2910 to 3263 pounds |
| Front tire | 7-16 |
| Rear tire | 11.2-26 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| GEAS TG Operator Manual (1690-912-001-0A) |
