RK Tractors RK24H
| | 2017 - |
| Sub-Compact Utility tractor | | TYM built |
|
Series map:
RK19H
RK24H
19.0hp
24.0hp
| Production |
| Distributor | RK Tractors (a part of Rural King)
|
| Manufacturer | TYM
|
| Sub-Compact Utility tractor |
| Original price was $10,499 in 2017 |
| RK Tractors RK24H Power |
| Engine (gross) | 24 hp
17.9 kW
|
| PTO (claimed) | 18.8 hp
14.0 kW
|
| Mechanical |
| Four-wheel drive |
| Power steering |
| Wet disc brakes |
| Two-post ROPS. |
| Hydraulics |
| Valves | 1
|
| Pump flow | 4.18 gpm
15.8 lpm
|
| Total flow | 6.95 gpm
26.3 lpm
|
| Steering flow | 2.77 gpm
10.5 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | position control
|
| Rear lift (at ends) | 1323 lbs
600 kg
|
| Rear lift (at 24"/610mm) | 1058 lbs
479 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | electro-hydraulic
|
| Rear PTO Type | 540 (1.375)
|
| Mid PTO Type | 2000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 40
|
| Battery volts | 12
|
| References |
 |
| RK24 Hydrostatic Operator's Manual published in 2018 |
