New Holland T4.110
|
|
| Production | |
| Manufacturer | New Holland |
| Utility tractor | |
| New Holland T4.110 Engine | |
| FPT 3.4L 4-cyl diesel | |
| Fuel tank | 30.3 gal 114.7 L |
| Exhaust fluid (DEF) | 2.8 gal 10.6 L |
 Engine details ... | |
| New Holland T4.110 Transmissions | |
| 12-speed mechanical shuttle | |
| 12-speed power shuttle | |
| 24-speed two-speed power shift | |
 Transmission details ... |
| New Holland T4.110 Power | |
| Engine (gross) | 107 hp 79.8 kW |
| PTO (claimed) | 93 hp 69.4 kW |
| Drawbar (tested) | 73.4 hp 54.7 kW |
| PTO (tested) | 96.0 hp 71.6 kW |
 Performance test details ... | |
| Mechanical | |
| Two- or four-wheel drive | |
| Final drives | inboard planetary |
| Power steering | |
| Wet disc brakes | |
| VisionView Cab standard. Two-post ROPS available. | |
| Photos | |
 | |
 New Holland T4.110 photos... | |
| Hydraulics | |
| Type | open center |
| Valves | 2 or 3 |
| Pump flow | 16.9 gpm 64.0 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | top-link draft sensing |
| Rear lift (at ends) | 7351 lbs 3334 kg |
| Rear lift (at 24"/610mm) | 4339 lbs 1968 kg |
| Rear Arms | telescopic link ends |
| Drawbar | Cat. 2 |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 |
| 540E OptOptional | |
| 1000 OptOptional | |
| Dimensions & Tires | |
| 2WD Wheelbase | 92.2 inches 234 cm |
| 4WD Wheelbase | 90 inches 228 cm |
| Weight | 6989 to 8157 pounds |
| Front tire | 7.50-16 |
| 2WD Rear tire | 16.9R30 |
 Full dimensions and tires ... | |
| New Holland T4.110 attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| T4 Series Utility published in 2015, by New Holland | |
| T4 Series published in 2017, by New Holland |
