Tractors > Kubota > M6-111

Kubota M6-111

Kubota M6-111 tractor photo
2015 -    M6 Series
Utility tractor
Series next:Kubota M6-131
Series back:Kubota M6-101




Kubota M6-111 Engine:

   Kubota 3.8L 4-cyl diesel
full engine details ...


Fuel:50.2 gal [190.0 L]
Exhaust fluid (DEF):5.3 gal [20.1 L]

3-Point Hitch:

Rear Type:II
Control:electronic lower-link draft sensing
Rear lift (at 24"/610mm):6834 lbs [3099 kg]
 9447 lbs [4285 kg] *Optional. Advertised lift. Actual tested lift was 8613 pounds.
Rear Arms:telescopic lower link ends and stabilizers

Power Take-off (PTO):

Rear PTO:independent
Clutch:hydraulic wet disc
Rear RPM:540/1000
Engine RPM:540@2405

Dimensions & Tires:

Wheelbase:95.9 inches [243 cm]
Weight:9789 lbs [4440 kg]
Front tire:13.6R24
Rear tire:18.4R34
full dimensions and tires ...

Kubota M6-111 attachments:

 front-end loader
all M6-111 attachments ...

M6-111 Serial Numbers:

- Serial numbers unknown -

Kubota M6-111 Power:

Engine (gross):114.1 hp [85.1 kW]
Engine (net):106.8 hp [79.6 kW]
PTO (claimed):92 hp [68.6 kW]
PTO (tested):96.48 hp [71.9 kW]
power test details ...


Chassis:4x4 MFWD 4WD
Differential lock:electro-hydraulic front and rear
Brakes:hydraulic wet disc
Cab:Grand X Cab standard with air-condiitoning.


Valves:2 to 4
Pump flow:18.7 gpm [70.8 lpm]
Steering flow:16 gpm [60.6 lpm]


Charging system:alternator
Charging amps:130
