John Deere 5100M
2012 - 2022 5M Series Utility tractor
Production Manufacturer John Deere
Utility tractor Built in Augusta, Georgia, USA Original price was $67,976 in 2021
Mechanical Two- or four-wheel drive Final drives inboard planetary
Differential lock electro-hydraulic
Power steering Hydraulic wet disc brakes Isolated open operator station with foldable two-post ROPS. Optional premium open station features extended fenders and integral work lights. Standard and premium cabs available with air-conditioning.
Hydraulics Type open center
Pump flow 18.4 gpm69.6 lpm
Total flow 24.7 gpm93.5 lpm
Tractor hitch Rear Type II/I
Control lower-link draft sensing
Rear lift (at 24"/610mm) 4600 lbs2086 kg
5600 lbsOpt Optional 2540 kg
Power Take-off (PTO) Rear PTO independent
Clutch electro-hydraulic
Rear PTO Type 540/540E
540/540E/1000 Opt Optional
Electrical Ground negative
Charging system alternator
Battery volts 12
References 5M Series published in 2015, by John Deere 5M Series published in 2016, by John Deere 5M Series published in 2018, by John Deere* Operator's Manual 5094M, 5090M, 5100M, 5100MH, 5100ML, 5115M and 5115ML (FT4) Tractors (OMSU54598) published in 2017 *Publication contains known errors.
