Landini 9880HC
|
|
| Production | |
| Manufacturer | Landini |
| High-Clearance tractor | |
| Landini 9880HC Engine | |
| Perkins 3.9L 4-cyl diesel | |
| Fuel tank | 40.2 gal 152.2 L |
 Engine details ... | |
| Landini 9880HC Transmissions | |
| 12-speed synchromesh shuttle | |
| 24-speed creeper | |
 Transmission details ... |
| Landini 9880HC Power | |
| Engine | 93 hp 69.4 kW |
| PTO (claimed) | 84 hp 62.6 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Power steering | |
| Hydraulic wet disc brakes | |
| Trailer brakes | hydraulic OptOptional |
| pneumatic OptOptional | |
| Cab standard with available air-conditioning. | |
| Photos | |
| No photos of the Landini 9880HC are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pump flow | 11.7 gpm 44.3 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift | 9590 lbs 4350 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 540@1967 |
| 1000@1954 | |
| Dimensions & Tires | |
| 2WD Wheelbase | 88.4 inches 224 cm |
| 4WD Wheelbase | 87.4 inches 221 cm |
| Weight | 7926 to 8951 pounds |
| Front tire | 9.00-16 |
| 2WD Rear tire | 13.6R38 |
 Full dimensions and tires ... | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 45 |
| Battery volts | 12 |
| References | |
 | |
| 9880HC published in 1992, by Landini |
