New Holland T5.105
|
|
| Production | |
| Manufacturer | New Holland (a part of CNH) |
| Utility tractor | |
| Variants | |
| T5.105 | base model |
| T5.115 Electro Command | premium model |
| Farmall 105U | similar CaseIH model |
| New Holland T5.105 Engine | |
| FPT 3.4L 4-cyl diesel | |
| Fuel tank | 37 gal 140.0 L |
 Engine details ... | |
| New Holland T5.105 Transmissions | |
| 12-speed power shuttle | |
| 20-speed creeper power shuttle | |
| 24-speed two-speed power shift | |
 Transmission details ... |
| New Holland T5.105 Power | |
| Engine (gross) | 106 hp 79.0 kW |
| PTO (claimed) | 91 hp 67.9 kW |
| Drawbar (tested) | 70.3 hp 52.4 kW |
| PTO (tested) | 99.3 hp 74.0 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | Electro-hydraulic rear. Limited slip front. |
| Steering | hydrostatic power |
| Hydraulic wet disc brakes | |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the New Holland T5.105 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center gear pumps |
| Valves | 2 to 3 |
| Pump flow | 16.1 gpm 60.9 lpm |
| 21.1 gpm (optional) 79.9 lpm | |
| Steering flow | 10 gpm 37.9 lpm |
| 11.4 gpm (optional) 43.1 lpm | |
| Tractor hitch | |
| Rear Type | II |
| Control | electronic draft control |
| Rear lift (at 24"/610mm) | 6392 lbs 2899 kg |
| 10452 lbs (optional) 4741 kg | |
| Rear Arms | flexible lower link ends with telescopic stabilizers |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic |
| Rear PTO Type | 540/1000 |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| Wheelbase | 92.5 inches 234 cm |
| Weight | 9370 lbs 4250 kg |
 Full dimensions and tires ... | |
| New Holland T5.105 attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 120 |
| Battery CCA | 960 |
| Battery volts | 12 |
| References | |
 | |
| T5 Series Tractors published in 2013, by New Holland |
