CaseIH Maxxum 100
|
|
| Production | |
| Manufacturer | CaseIH (a part of CNH) |
| Utility tractor | |
| Built in Basildon, England | |
| Variants | |
| T6010 | similar New Holland model |
| CaseIH Maxxum 100 Engine | |
| FPT 4.5L 4-cyl diesel | |
| Fuel tank | 46.5 gal 176.0 L |
 Engine details ... | |
| CaseIH Maxxum 100 Transmissions | |
| 16-speed partial power shift | |
| 17-speed partial power shift | |
 Transmission details ... |
| CaseIH Maxxum 100 Power | |
| Engine (gross) | 99 hp 73.8 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Hydraulic wet disc brakes | |
| Cab standard with air-conditioning. |
| Photos | |
| No photos of the CaseIH Maxxum 100 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| closed center OptOptional | |
| Pump flow | 21.1 gpm (open center) 79.9 lpm |
| 29.9 gpm (closed center) 113.2 lpm | |
| Steering flow | 10.5 gpm 39.7 lpm |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| Front PTO | independent OptOptional |
| Clutch | 1000:2120 |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| Wheelbase | 95 inches 241 cm |
| Weight | 10560 lbs 4790 kg |
| Front tire | 13.6R24 |
| Rear tire | 16.9R34 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| Maxxum Series 101-141HP Rated Power published in 2010, by CaseIH |
