J.I. Case 600
| | 1957 |
| 600 Series | | Standard-tread tractor |
|
Series map:
600
77.8hp*
*Estimated engine power for comparison only.
| Production |
| Manufacturer | J.I. Case
|
| Standard-tread tractor |
| Built in Racine, Wisconsin, USA |
| Total built | 1,515
|
| J.I. Case 600 Power |
| Belt (claimed) | 70 hp
52.2 kW
|
| Mechanical |
| Two-wheel drive |
| Steering | power assist
|
| Disc brakes |
| Open operator station. |
| Capacity |
| Fuel | 30 gal
113.6 L
|
| Hydraulic system | 3.5 gal
13.2 L
|
| Hydraulics |
| Type | open center OptOptional
|
| Capacity | 3.5 gal
13.2 L
|
| Pressure | 1000 psi
69.0 bar
|
| Pump flow | 15 gpm
56.8 lpm
|
| Power Take-off (PTO) |
| Rear PTO | independent OptOptional
|
| Clutch | mechanical wet disc
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540@1475
|
| Belt Pulley |
| Diameter | 13.5 inches
34 cm
|
| Width | 8.25 inches
20 cm
|
| RPM | 944
|
| Speed | 3338 ft/min
1017.42 meters/min
|
| Electrical |
| Ground | negative
|
| Charging system | generator
|
| Charging amps | 12
|
| Batteries | 2
|
| Battery volts | 6
|
| References |
 |
| 600 Tractors - Diesel and LP-Gas published in 1956, by J.I. Case |
| Operator's Instruction Manual 600 Series Diesel Tractors (6425) published in 1956 |
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on August 1, 2024 |
