John Deere 6210R



John Deere 6210R tractor photo
2012 - 2014
6R Series
Row-Crop tractor
Series map:
6190R
6210R
190.0hp
210.0hp
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Waterloo, Iowa, USA
Original price was $166,924 in 2014 with AutoQuad
John Deere 6210R Engine
John Deere 6.8L 6-cyl diesel
Fuel tank95 gal
359.6 L
 107 gal (optional)
405.0 L
Engine details ...
John Deere 6210R Transmissions
16-speed partial power shift
20-speed partial power shift
infinitely variable transmission
24-speed eight-speed power shift
Transmission details ...
John Deere 6210R Power
Engine (gross)210 hp
156.6 kW
Engine (max)231 hp
172.3 kW
PTO (claimed)175 hp
130.5 kW
Drawbar (tested)170.30 hp
127.0 kW
PTO (tested)205.18 hp
153.0 kW
Performance test details ...
Mechanical
Four-wheel drive
Differential lockelectro-hydraulic rear lock with wet disc clutch
Steeringhydrostatic power
Hydraulic wet disc brakes
ComfortView cab standard with air-conditioning. Optional adaptive hydraulic cab suspension. GreenStar and AutoTrac ready with ISOBUS connector.
Photos
No photos of the John Deere 6210R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center pressure flow compensated (PFC)
Pressure2900 psi
200.0 bar
Valves2 to 4
Pump flow41 gpm
155.2 lpm
SCV flow26.4 gpm
99.9 lpm
Tractor hitch
Rear Type3
Controlelectro-hydraulic draft sensing
Rear lift (at ends)21,050 lbs
9548 kg
Rear lift (at 24"/610mm)12,213 lbs
5539 kg
DrawbarCategory 3 with 3,525 to 6,170 pound load rating
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000 (1.375)
 540/540E/1000 (1.375)
 540/1000/1000E (1.375)
 540/1000 (1.75)
 540/540E/1000 (1.75)
 540/1000/1000E (1.75)
Engine RPM540@1932
 540E@1775
 1000@1932
 1000E@1775
Dimensions & Tires
Wheelbase110.2 inches
279 cm
Weight17200 to 18180 pounds
Front tire420/90R30
Rear tire480/80R46
Full dimensions and tires ...
John Deere 6210R attachments
front-end loader
Attachment details ...
6210R Serial Number Location
John Deere 6210R serial number location
Serial number plate on the right side of the tractor frame, above the front axle.
Electrical
Groundnegative
Charging systemalternator
Charging amps120
 200 (optional)
Battery volts12
References
6210R references literature
6R Series Tractors published in 2012, by John Deere
Operator's Manual Tractors 6140R, 6150R, 6150RH, 6170R, 6190R and 6120R (OMAL211531) published in 2014
