John Deere 6105R Transmission


John Deere 6105R tractor photo
2012 - 2014
6R Series
Utility tractor
Series:6105R6115R
6110R
Transmissions overview
16-speed partial power shift
24-speed partial power shift
infinitely variable transmission
Transmission
Transmission:PowerQuad Plus
Type:partial power shift
Gears:16 forward and reverse
Four power shift gears (1-4) in four synchronized ranges (A-D) with left-hand reverser.
Speeds
With 16.9R30 rear tires. Reverse speeds are about 5% faster than forward.
6105R PowerQuad Plus partial power shift speeds
Transmission
Transmission:AutoQuad Plus Eco
Type:partial power shift
Gears:24 forward and reverse
Clutch:PermaClutch II hydraulic wet disc
Four power shift gears (1-4) in six synchronized ranges (A-F) with left-hand reverser. Available in 40 km/h and 50 km/h versions.
Speeds
With 16.9R30 rear tires. Reverse speeds are about 5% faster than forward. 50 km/h version shown, 40 km/h only affects gear F4.
6105R AutoQuad Plus Eco partial power shift speeds
Transmission
Transmission:AutoPowr IVT
Type:infinitely variable transmission
Gears:infinite forward and reverse
