Bolens G214 G2104


No photo available
1984 - 1990
Iseki built
Production
Distributor:Bolens
Manufacturer:Iseki
Variants
G212:2WD
G214:4WD
Iseki TE3210
Bolens G214 Power
Engine:21 hp
15.7 kW
Bolens G214 Engine
Iseki 1.2L 3-cyl diesel
Fuel tank:6 gal
22.7 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 2WD
Differential lock:mechanical rear
Steering:manual
Brakes:mechanical internal expanding
Cab:Open operator station.
Transmission:12-speed
Transmission details ...
Photos
No photos of the Bolens G214 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center
Pressure:2000 psi
137.9 bar
Pump flow:4.8 gpm
18.2 lpm
Tractor hitch
Rear Type:0
Control:position control
Rear lift:1400 lbs
635 kg
Power Take-off (PTO)
Rear RPM:540/1000 (1.375)
Engine RPM:540@2108
1000@2444
Dimensions & Tires
Wheelbase:59 inches
149 cm
Weight:1676 lbs
760 kg
Front tire:6.00-12
Rear tire:12.4-16
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging volts:35
Battery CCA:305
Battery volts:12
Battery AH:45
