Bolens G212 G2102


Bolens G212 G2102 tractor photo
1984 - 1990
Compact Utility tractor
Iseki built
Production
Distributor:Bolens
Manufacturer:Iseki
Type:Compact Utility tractor
Variants
G212:2WD
G214:4WD
Iseki TE3210
Bolens G212 Power
Engine:21 hp
15.7 kW
Bolens G212 Engine
Iseki 1.2L 3-cyl diesel
Fuel tank:6.1 gal
23.1 L
Engine details ...
Mechanical
Chassis:4x2 2WD
Differential lock:mechanical rear
Steering:manual
Brakes:mechanical internal expanding
Cab:Open operator station.
Transmission:12-speed
Transmission details ...
Hydraulics
Type:open center
Pressure:2000 psi
137.9 bar
Pump flow:4.8 gpm
18.2 lpm
Tractor hitch
Rear Type:0
Control:position control
Rear lift:1400 lbs
635 kg
Power Take-off (PTO)
Rear RPM:540/1000 (1.375)
Engine RPM:540@2108
1000@2444
Dimensions & Tires
Wheelbase:59 inches
149 cm
Weight:1588 lbs
720 kg
Front tire:4.00-12
Rear tire:12.4-16
Full dimensions and tires ...
G212 Serial Numbers
Location:Serial number plate on the left side of the main tractor frame, above the front axle.
Electrical
Ground:negative
Charging system:alternator
Charging volts:35
Battery CCA:305
Battery volts:12
Battery AH:45
