Farmall MDV
| 1942 - 1952 |
High-Clearance tractor |
|
Production |
Manufacturer: | Farmall (a part of International Harvester)
|
Type: | High-Clearance tractor
|
Factory: | Rock Island, Illinois, USA
|
The MDV was the "vegetable", or high-clearance version of the Farmall MD. |
Variants |
MD: | row-crop
|
MV: | gasoline engine
|
Farmall MDV Power |
PTO (claimed): | 33 hp 24.6 kW
|
Plows: | 3 (14-inch)
|
Mechanical |
Chassis: | 4x2 2WD
|
Steering: | manual
|
Brakes: | mechanical contracting band
|
Cab: | Open operator station.
|
Transmission: | 5-speed
|
Transmission details ... |
Power Take-off (PTO) |
Rear RPM: | 540
|
Page information |
Last update: | May 29, 2015
|
Copyright: | Copyright 2021 TractorData LLC
|
Contact: | Peter@TractorData.com
|
