CaseIH Steiger 600 Quadtrac Tests

CaseIH Steiger 600 Quadtrac tractor photo
2011 -
Articulated Crawler tractor
Steiger 535QT
Series:Steiger 550 QuadtracSteiger 600 Quadtrac
Steiger 620 Quadtrac
OCED Tractor Test 2049
Steiger 600 Quadtrac fuel use from test 849
OCED Tractor Test 2049
Diesel 16-speed crawler
November 15 - 19, 2012
Link: OCED Tractor Test 2049 file
PTO performance
Max power:535.88 hp
399.6 kW
Fuel use:27.9 gal/hour
105.6 l/hour
Power at rated engine speed:476.83 hp
355.6 kW
Fuel use:26.3 gal/hour
99.5 l/hour
Power at rated PTO speed:517.80 hp
386.1 kW
Fuel use:27.6 gal/hour
104.5 l/hour
Drawbar performance
Max power:476.39 hp
355.2 kW
Fuel use:29.7 gal/hour
112.4 l/hour
Gear 5 used for power test.
Max pull:56424 lbs
25593 kg
Gear 1 used for pull test.
