Tractors > CaseIH > Steiger 620 Quadtrac

CaseIH Steiger 620 Quadtrac Tests

CaseIH Steiger 620 Quadtrac tractor photo

2014 - 2023

Steiger Quadtrac Series

Articulated Crawler tractor

Series map:

Steiger 645 Quadtrac↑ 2024-2025

Steiger 580 Quadtrac

Steiger 620 Quadtrac

580.0hp

620.0hp

Steiger 600 Quadtrac↓ 2011-2021

OCED Tractor Test 2165

Steiger 620 Quadtrac fuel use from test 1046

OCED Tractor Test 2165
Diesel 16-speed crawler September 30 - October 10, 2016 Link: OCED Tractor Test 2165 file
PTO performance
Max power	539.07 hp 402.0 kW
Fuel use	27.9 gal/hour 105.6 l/hour
Power at rated engine speed	479.06 hp 357.2 kW
Fuel use	26.1 gal/hour 98.8 l/hour
Power at rated PTO speed	531.84 hp 396.6 kW
Fuel use	27.2 gal/hour 103.0 l/hour
Drawbar performance
Max power	507.20 hp 378.2 kW
Fuel use	30.5 gal/hour 115.4 l/hour
Gear 5 used for power test.
Max pull	57556 lbs 26107 kg
Gear 2 used for pull test.
