CaseIH Magnum 315
|
|
| Production | |
| Manufacturer | CaseIH (a part of CNH) |
| Row-Crop tractor | |
| Built in Racine, Wisconsin, USA | |
| CaseIH Magnum 315 Engine | |
| FPT 8.7L 6-cyl diesel | |
| Fuel tank | 168 gal 635.9 L |
| Exhaust fluid (DEF) | 23.6 gal 89.3 L |
 Engine details ... | |
| CaseIH Magnum 315 Transmissions | |
| 19-speed full power shift | |
| 18-speed full power shift | |
| 23-speed creeper | |
| continuously variable transmission | |
 Transmission details ... |
| CaseIH Magnum 315 Power | |
| Engine (gross) | 312 hp 232.7 kW |
| Engine (max) | 347 hp 258.8 kW |
| PTO (claimed) | 265 hp 197.6 kW |
| Drawbar (tested) | 231.39 hp 172.5 kW |
| PTO (tested) | 315.72 hp 235.4 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Magnum Surveyor cab standard. Optional cab suspension. |
| Photos | |
| No photos of the CaseIH Magnum 315 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | pressure-flow compensating |
| Rear valves | 4 to 6 |
| Total flow | 44 gpm 166.5 lpm |
| 59 gpm (optional) 223.3 lpm | |
| 75 gpm (optional) 283.9 lpm | |
| Tractor hitch | |
| Rear Type | 3/3N |
| 4N/3 (optional) | |
| Rear lift | 14,375 lbs (3/3N 109cm links) 6520 kg |
| 16,375 lbs (3/3N 96cm links) 7427 kg | |
| 15,400 lbs (3/3N 109cm links opt.) 6985 kg | |
| 17,400 lbs (3/3N 96cm links opt.) 7892 kg | |
| 17,400 lbs (4N/3 109cm links) 7892 kg | |
| 19,400 lbs (4N/3 96cm links) 8799 kg | |
| Front Hitch | optional |
| Front lift | 9,426 lbs 4275 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 1000 (1.75) |
| 540/1000 (1.375)OptOptional | |
| Engine RPM | 540@1804 |
| 1000@1804 | |
| Front PTO | independent OptOptional |
| Front PTO Type | 1000 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 120 inches 304 cm |
| Weight | 27,800 lbs 12610 kg |
 Full dimensions and tires ... | |
| Magnum 315 Serial Number Location | |
 | |
| Serial number plate on the right side of the tractor frame, above the front axle. |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 200 |
| Batteries | 2 |
| Battery volts | 12 |
| References | |
 | |
| Magnum Series Tractors published in 2011, by CaseIH | |
| Magnum Series Tractors New 2011 Preview published in 2010, by CaseIH |
