CaseIH Farmall DX24
|
|
| Production | |
| Manufacturer | CaseIH (a part of CNH) |
| Compact Utility tractor | |
| Variants | |
| TC24DA | similar New Holland model |
| CaseIH Farmall DX24 Engine | |
| Shibaura 1.1L 3-cyl diesel | |
| Fuel tank | 5.3 gal 20.1 L |
 Engine details ... | |
| CaseIH Farmall DX24 Transmissions | |
| 9-speed gear | |
| hydrostatic | |
 Transmission details ... |
| CaseIH Farmall DX24 Power | |
| Engine (gross) | 24 hp 17.9 kW |
| Gear PTO (claimed) | 19.5 hp 14.5 kW |
| Hydro PTO (claimed) | 18.5 hp 13.8 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. Soft cab optional. |
| Hydraulics | |
| Type | open center |
| Valves | 2 OptOptional |
| Pump flow | 4.9 gpm 18.5 lpm |
| Total flow | 7.65 gpm 29.0 lpm |
| Steering flow | 2.75 gpm 10.4 lpm |
| Tractor hitch | |
| Rear Type | I |
| Rear lift (at 24"/610mm) | 1265 lbs 573 kg |
| Power Take-off (PTO) | |
| Gear Rear PTO | transmission |
| Hydro Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Gear Mid PTO | transmission |
| Hydro Mid PTO | independent |
| Mid PTO Type | 2000 |
| Dimensions & Tires | |
| Wheelbase | 57.5 inches 146 cm |
| Weight | 1502 to 1600 pounds |
 Full dimensions and tires ... | |
| CaseIH Farmall DX24 attachments | |
| 54" mid-mount mower deck | |
| 60" mid-mount mower deck | |
| snowblower | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| DX Series Farmall Tractors published in 2004, by CaseIH | |
| DX Series Farmall Tractors published in 2003, by CaseIH | |
| DX Series Farmall Tractors and Integrated Implements published in 2004, by CaseIH |
