CaseIH Farmall DX21


CaseIH Farmall DX21 tractor photo
2003 - 2005
Farmall DX Series
Compact Utility tractor
Series map:
Farmall DX21
Farmall DX24
21.0hp
24.0hp
Production
ManufacturerCaseIH (a part of CNH)
Compact Utility tractor
Variants
TC21DAsimilar New Holland model
CaseIH Farmall DX21 Engine
Shibaura 1.0L 3-cyl diesel
Fuel tank5.3 gal
20.1 L
Engine details ...
CaseIH Farmall DX21 Power
Engine (gross)21 hp
15.7 kW
Gear PTO (claimed)17 hp
12.7 kW
Hydro PTO (claimed)16 hp
11.9 kW
Mechanical
Four-wheel drive
Power steering
Wet disc brakes
Two-post folding ROPS. Soft cab optional.
Photos
No photos of the CaseIH Farmall DX21 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Valves2 OptOptional
Pump flow4.9 gpm
18.5 lpm
Total flow7.65 gpm
29.0 lpm
Steering flow2.75 gpm
10.4 lpm
Tractor hitch
Rear TypeI
Rear lift (at 24"/610mm)1265 lbs
573 kg
Power Take-off (PTO)
Gear Rear PTOtransmission
Hydro Rear PTOindependent
Rear PTO Type540 (1.375)
Gear Mid PTOtransmission
Hydro Mid PTOindependent
Mid PTO Type2000
Dimensions & Tires
Wheelbase57.5 inches
146 cm
Weight1495 to 1592 pounds
Full dimensions and tires ...
CaseIH Farmall DX21 attachments
54" mid-mount mower deck
60" mid-mount mower deck
snowblower
front-end loader
backhoe
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
Farmall DX21 references literature
DX Series Farmall Tractors published in 2004, by CaseIH
DX Series Farmall Tractors published in 2003, by CaseIH
DX Series Farmall Tractors and Integrated Implements published in 2004, by CaseIH
