John Deere 5525 Hi-Crop


John Deere 5525 Hi-Crop tractor photo
2005 - 2008
High-Clearance tractor
Series map:
5525 Hi-Crop
91.0hp
Production
ManufacturerJohn Deere
High-Clearance tractor
Built in Augusta, Georgia, USA
Variants
5525utility
5525Nnarrow-profile
5525 Hi-Crophigh-clearance
John Deere 5525 Hi-Crop Engine
John Deere 4.5L 4-cyl diesel
Fuel tank25.5 gal
96.5 L
Engine details ...
John Deere 5525 Hi-Crop Transmissions
12-speed partially synchronized
16-speed power shuttle
Transmission details ...
John Deere 5525 Hi-Crop Power
Engine (gross)91 hp
67.9 kW
PTO (claimed)75 hp
55.9 kW
PTO (tested)77.96 hp
58.1 kW
Performance test details ...
Mechanical
Four-wheel drive
Steeringhydrostatic power
Differential hydraulic wet disc brakes
Two-post ROPS on straddle-deck. Flat-deck platform optional.
Photos
No photos of the John Deere 5525 Hi-Crop are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Rear valves0 to 3
Mid valves0 to 3
Pump flow18.4 gpm
69.6 lpm
Steering flow6.6 gpm
25.0 lpm
Tractor hitch
Rear TypeII/I
Rear lift (at 24"/610mm)3,374 lbs
1530 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540
 540/540E optional
Dimensions & Tires
Wheelbase85.7 inches
217 cm
Weight7,145 lbs
3240 kg
Front tire13.6-38
Rear tire13.6-38
Full dimensions and tires ...
5525 Hi-Crop Serial Numbers
Location:Left side of tractor frame above the front axle.
Electrical
Groundnegative
Charging systemalternator
Charging amps70
Battery CCA950
Battery volts12
Battery GroupBCI 31
References
5525 Hi-Crop references literature
Specialty Tractors published in 2008, by John Deere
