New Holland TV6070
| Production |
| Manufacturer: | New Holland
|
| New Holland TV6070 Power |
| Engine (gross): | 155 hp
115.6 kW
|
| PTO (claimed): | 105 hp
78.3 kW
|
| Drawbar (tested): | 80.25 hp
59.8 kW
|
| PTO (tested): | 115.85 hp
86.4 kW
|
| power test details ... |
| Mechanical |
| Chassis: | 4x4 articulated 4WD
|
| Steering: | hydrostatic power
|
| Brakes: | hydraulic caliper disc
|
| Cab: | Cab standard with air-conditioning.
|
| Transmission: | hydrostatic
|
 Transmission details ... |
| Capacity |
| Fuel: | 55 gal
208.2 L
|
| Hydraulic system: | 13.5 gal
51.1 L
|
| Hydraulics |
| Type: | closed center load sensing
|
| Capacity: | 13.5 gal
51.1 L
|
| Rear valves: | 3
|
| Front valves: | 2
|
| Total flow: | 29.5 gpm
111.7 lpm
|
| | 35 gpm
132.5 lpm (optional)
|
| Tractor hitch |
| Rear Type: | II
|
| Rear lift (at 24"/610mm): | 6500 lbs
2948 kg
|
| | 8700 lbs
3946 kg *Optional
|
| Front Hitch: | II*Optional
|
| Front lift (at 24"/610mm): | 4000 lbs
1814 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/1000
|
| Front RPM: | 540/1000
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 120
|
| Batteries: | 2
|
| Battery CCA: | 950
|
| Battery volts: | 12
|
| Battery Group: | 31
|
