John Deere 6410L


John Deere 6410L tractor photo
1999 - 2002
6000 TEN Series
Orchard/Vineyard tractor
6400L
Series:6310L6410L6510L
6420L
Production
Manufacturer:John Deere
Type:Orchard/Vineyard tractor
Factory:Mannheim, Baden-W├╝rttemberg, Germany
Variants
6410:utility tractor
6410L:low-profile ROPS
6410S:low-profile cab
John Deere 6410L Power
Engine (gross):104 hp
77.6 kW
PTO (claimed):90 hp
67.1 kW
John Deere 6410L Engine
John Deere 4.5L 4-cyl diesel
Fuel tank:30.7 gal
116.2 L
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Differential lock:electro-hydraulic wet disc
Steering:power
Brakes:hydraulic wet disc
Cab:Two-post folding ROPS.
Transmissions:12-speed fully synchronized
 16-speed power shuttle
 16-speed partial power shift
 38-speed four-speed power shift
Transmission details ...
Photos
No photos of the John Deere 6410L are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:closed center load sensing
Pressure:2900 psi
200.0 bar
Valves:1 to 4
Pump flow:25.4 gpm
96.1 lpm
 18.9 gpm
71.5 lpm *Optional
Tractor hitch
Rear Type:II
Control:electronic lower-link draft sensing
Rear lift:5915 lbs
2683 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540 (1.375)
 540/1000 (1.375)*Optional
Dimensions & Tires
Wheelbase:94.5 inches
240 cm
Weight:7607 to 8246 pounds
Front tire:27/9.5-15
2WD Rear tire:18.4-26
Full dimensions and tires ...
6410L Serial Numbers
Location:Serial number plate on the right side of the tractor frame.
Electrical
Ground:negative
Charging system:alternator
Charging amps:90
Battery CCA:850
 1230*Optional
Battery volts:12
Battery AH:110
 154*Optional
