Claas Arion 620

Claas Arion 620 tractor photo
2007 - 2017
Model year
Arion 600 Series
Row-Crop tractor
Series map:
Arion 610
Arion 620
Arion 630
Row-Crop tractor
Arion 620deluxe model
Arion 620Ceconomy model
Claas Arion 620 Engine
John Deere 6.8L 6-cyl diesel
Fuel tank87.2 gal
330.1 L
Engine details ...
Claas Arion 620 Transmission
24-speed partial power shift with power shuttle
Transmission details ...
Claas Arion 620 Power
Engine135 hp
100.7 kW
Four-wheel drive
Power steering
Trailer brakespneumatic OptOptional
Cab standard with air-conditioning.
Typeload sensing
Pressure2901 psi
200.0 bar
Valves2 to 6
Total flow29.1 gpm
110.1 lpm
Power Take-off (PTO)
Rear PTO Type540/1000
 540/540E/1000/1000E (optional)
Dimensions & Tires
Wheelbase111 inches
281 cm
Weight13120 lbs
5951 kg
Front tire16.9R28
Rear tire20.8R38
Full dimensions and tires ...
Arion 620 references literature
Arion published in 2007, by New Rules - The Arion By Claas
Arion published in 2010, by Claas
