New Holland TN85DA
|
|
| Production | |
| Manufacturer | New Holland |
| Utility tractor | |
| Built in Jesi, Italy | |
| New Holland TN85DA Engine | |
| Iveco 4.5L 4-cyl diesel | |
| Fuel tank | 23.5 gal 88.9 L |
 Engine details ... | |
| New Holland TN85DA Transmissions | |
| 16-speed partially synchronized with mechanical shuttle | |
| 16-speed partially synchronized with power shuttle | |
 Transmission details ... |
| New Holland TN85DA Power | |
| Engine (gross) | 80 hp 59.7 kW |
| PTO (claimed) | 69 hp 51.5 kW |
| Drawbar (tested) | 62.2 hp 46.4 kW |
| PTO (tested) | 72.0 hp 53.7 kW |
 Performance test details ... | |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | mechanical rear |
| Steering | hydrostatic power |
| Differential wet disc brakes | |
| Cab standard. | |
| Photos | |
| No photos of the New Holland TN85DA are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2755 psi 190.0 bar |
| Valves | 1 to 4 |
| Pump flow | 15 gpm 56.8 lpm |
| Steering flow | 9.4 gpm 35.6 lpm |
| Tractor hitch | |
| Rear Type | II/I |
| Rear lift (at 24"/610mm) | 3960 lbs 1796 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 89.1 inches (2WD) 226 cm |
| 86 inches (4WD) 218 cm | |
| Weight | 6230 to 6770 pounds |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 85 |
| Battery CCA | 730 |
| Battery volts | 12 |
| References | |
 | |
| New 4-Cylinders published in 2005, by New Holland | |
| TN-A Series Utility Tractors published in 2006, by New Holland |
