New Holland TN85A


New Holland TN85A tractor photo
2004 - 2008
TN-A Series
Utility tractor
Series:TN75ATN85ATN95A
Production
Manufacturer:New Holland
Type:Utility tractor
Factory:Jesi, Italy
Variants
TN85A:ROPS
TN85DA:cab
TN85FA:narrow/orchard
New Holland TN85A Power
Engine (gross):80 hp
59.7 kW
PTO (claimed):69 hp
51.5 kW
Drawbar (tested):61.2 hp
45.6 kW
PTO (tested):72.0 hp
53.7 kW
power test details ...
New Holland TN85A Engine
Iveco 4.5L 4-cyl diesel
Fuel tank:23.5 gal
88.9 L
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:differential wet disc
Cab:ROPS. Canopy optional
Transmissions:12-speed partially synchronized with mechanical shuttle
 16-speed partially synchronized with mechanical shuttle
 16-speed partially synchronized with power shuttle
Transmission details ...
Photos
No photos of the New Holland TN85A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center
Pressure:2755 psi
190.0 bar
Valves:1 to 4
Pump flow:15 gpm
56.8 lpm
Steering flow:9.4 gpm
35.6 lpm
Tractor hitch
Rear Type:II/I
Rear lift (at 24"/610mm):3960 lbs
1796 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540
Engine RPM:540@2196
Dimensions & Tires
2WD Wheelbase:86.7 inches
220 cm
4WD Wheelbase:83.7 inches
212 cm
Weight:6008 to 6118 pounds
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:65
Battery CCA:730
Battery volts:12
