Cub Cadet Ex450
| | 2009 - 2011 |
| Ex Series | | Compact Utility tractor | | Yanmar built |
|
| Production |
| Distributor: | Cub Cadet
|
| Manufacturer: | Yanmar
|
| Type: | Compact Utility tractor
|
| Original price: | $21,299 (2009)
|
| Cub Cadet Ex450 Power |
| Engine: | 45 hp
33.6 kW
|
| PTO (claimed): | 37.5 hp
28.0 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | hydraulic power
|
| Cab: | ROPS standard
|
| Transmission: | 9-speed synchronized shuttle
|
 Transmission details ... |
| Capacity |
| Fuel: | 11.3 gal
42.8 L
|
| Front axle: | 8 qts
7.6 L
|
| Hydraulics |
| Type: | open center
|
| Pump flow: | 8.5 gpm
32.2 lpm
|
| Total flow: | 13 gpm
49.2 lpm
|
| Steering flow: | 4.5 gpm
17.0 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Rear lift (at 24"/610mm): | 2,464 lbs
1117 kg
|
| Power Take-off (PTO) |
| Rear PTO: | live
|
| Rear RPM: | 540
|
| Page information |
| Last update: | March 8, 2012
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
©2000-2021 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
