New Holland T5050
| | 2008 - 2013 |
| T5000 Series | | Utility tractor |
|
| Production |
| Manufacturer: | New Holland
|
| Type: | Utility tractor
|
| Factory: | Jesi, Italy
|
| New Holland T5050 Power |
| Engine (gross): | 95 hp
70.8 kW
|
| PTO (claimed): | 80 hp
59.7 kW
|
| Drawbar (tested): | 72.0 hp
53.7 kW
|
| PTO (tested): | 87.2 hp
65.0 kW
|
| power test details ... |
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD (optional)
|
| Differential lock: | mechanical rear standard
|
| | optional electrohydraulic front and rear
|
| Steering: | hydrostatic power
|
| Brakes: | hydraulic wet disc
|
| Cab: | Flat deck platform with ROPS. Cab optional with heat and air-conditioning.
|
| Transmissions: | 12-speed mechanical shuttle
|
| | 12-speed power shuttle
|
| | 20-speed mechanical shuttle
|
| | 24-speed power shuttle
|
 Transmission details ... |
| Photos |
| No photos of the New Holland T5050 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type: | open center
|
| Pressure: | 2,871 psi
198.0 bar
|
| Rear valves: | 2 to 3 (open or closed center)
|
| Mid valves: | 0 to 2
|
| Pump flow: | 16.1 gpm
60.9 lpm
|
| Steering flow: | 10.4 gpm
39.4 lpm
|
| Tractor hitch |
| Rear Type: | II
|
| Control: | mechanical lower-link draft sensing
|
| Rear lift (at 24"/610mm): | 5,475 lbs
2483 kg
|
| | 6,805 lbs
3086 kg (optional)
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | mechanical
|
| | electrohydraulic optional
|
| Rear RPM: | 540/1000 (1.375)
|
| Engine RPM: | 540@2199
1000@2261
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 120
|
| Battery CCA: | 960
|
| Battery volts: | 12
|
