Iseki TS2510
|
|
| Production | |
| Manufacturer | Iseki |
| Compact Utility tractor | |
| Variants | |
| TS2510F | 4WD |
| Iseki TS2510 Engine | |
| Isuzu 1.2L 2-cyl diesel | |
| Fuel tank | 7.9 gal 29.9 L |
 Engine details ... | |
| Iseki TS2510 Transmission | |
| 9-speed gear | |
 Transmission details ... |
| Iseki TS2510 Power | |
| Engine | 25 hp 18.6 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Open operator station. |
| Photos | |
| No photos of the Iseki TS2510 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 630@2600 |
| 773@2600 | |
| 990@2600 | |
| 1547@2600 | |
| Dimensions & Tires | |
| Wheelbase | 64.6 inches 164 cm |
| Weight | 2601 lbs 1179 kg |
| Front tire | 5.00-15 |
| Rear tire | 11.2/10-24 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| TS & TX Series published in 1975, by Iseki | |
| TS1610-TS2810 | |
| TS3510-TS2810-TS2510 published in 1976, by Iseki |
