John Deere 8300T
| | 1997 - 1999 |
| 8000/8000T Series | | Agricultural Crawler tractor |
|
Series map:
8200T
8300T
8400T
200.0hp*
222.2hp*
250.0hp*
*Estimated engine power for comparison only.
| Production |
| Manufacturer | John Deere
|
| Agricultural Crawler tractor |
| Built in Waterloo, Iowa, USA |
| Variants |
| 8300 | wheeled tractor
|
| 8300T | crawler tractor
|
| John Deere 8300T Power |
| PTO (claimed) | 200 hp
149.1 kW
|
| Drawbar (tested) | 175.88 hp
131.2 kW
|
| PTO (tested) | 226.19 hp
168.7 kW
|
 Performance test details ... |
| Mechanical |
| Drive | crawler
|
| Steering | hydrostatic power
|
| Hydraulic wet disc brakes |
| CommandView Cab standard |
| Capacity |
| Fuel | 130 gal
492.1 L
|
| Hydraulic system | 65 gal
246.0 L
|
| Hydraulics |
| Type | pressure/flow compensated (PFC)
|
| Capacity | 65 gal
246.0 L
|
| Pressure | 2900 psi
200.0 bar
|
| Valves | 3 to 5
|
| Pump flow | 30 gpm
113.6 lpm
|
| | 38 gpmOptOptional
143.8 lpm
|
| Tractor hitch |
| Rear Type | III/IIIN
|
| Rear lift | 15650 lbs
7098 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear RPM | 1000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 140
|
| Batteries | 2
|
| Battery volts | 12
|
| References |
 |
| 8000/8000T Series Tractors Product Information Handbook published in 1998, by John Deere |
