Ford 1910
| | 1983 - 1986 |
| Ten Compact Series | | Compact Utility tractor | | Shibaura built |
|
Series map:
1710
1910
2110
26.0hp
32.0hp
38.0hp
| Production |
| Distributor | Ford
|
| Manufacturer | Shibaura
|
| Compact Utility tractor |
| Built in Japan |
| Original price was $10,000 in 1986 |
| Ford 1910 Power |
| Engine | 32 hp
23.9 kW
|
| PTO (claimed) | 28.5 hp
21.3 kW
|
| Drawbar (tested) | 24.76 hp
18.5 kW
|
| PTO (tested) | 28.60 hp
21.3 kW
|
 Performance test details ... |
| Mechanical |
| Two- or four-wheel drive |
| Final drives | spur gear
|
| Differential lock | mechanical rear
|
| Steering | manual
|
| | power (4WD)
|
| Differential mechanical drum brakes |
| Two-post fixed ROPS. |
| Capacity |
| Fuel | 9.2 gal
34.8 L
|
| Hydraulic system | 7.4 gal
28.0 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 7.4 gal
28.0 L
|
| Pressure | 2133 psi
147.1 bar
|
| Pump flow | 5.1 gpm
19.3 lpm
|
| Total flow | 8.6 gpm
32.6 lpm
|
| Steering flow | 3.5 gpm
13.2 lpm
|
| Steering press. | 1000 psi
69.0 bar
|
| Tractor hitch |
| Rear Type | I
|
| Control | position control
|
| | draft control OptOptional
|
| Rear lift (at ends) | 3813 lbs
1729 kg
|
| Rear lift (at 24"/610mm) | 1584 lbs
718 kg
|
| Power Take-off (PTO) |
| Rear PTO | live
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540@2456
|
| 1910 Serial Number Location |
 |
| Serial number plate on the left side of the Ford 1910, near the clutch pedal. |
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 35
|
| Charging volts | 12
|
| Battery volts | 12
|
| Battery AH | 100
|
| References |
 |
| Ford Shop Manual by Peter Letourneau |
| Farm Loaders published in 1988, by Ford |
| 1000 Series Tractors published in 1985, by Ford |
| 1000 Series Tractors published in 1987, by Ford |
| Salesman's Reference published in 1986, by Ford |
| Sales Reference Guide published in 1986, by Ford |
