John Deere 6100D


John Deere 6100D tractor photo
2008 - 2012
6D Series
Utility tractor
6403
Series:6100D6115D
6105D
Production
Manufacturer:John Deere
Type:Utility tractor
Factory:Saltillo, Mexico
Original price:$45,299 (2011)
John Deere 6100D Power
Engine (gross):98.9 hp
73.7 kW
PTO (claimed):82 hp
61.1 kW
Drawbar (tested):74.66 hp
55.7 kW
PTO (tested):90.10 hp
67.2 kW
power test details ...
John Deere 6100D Engine
John Deere 4.5L 4-cyl diesel
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD (optional)
Steering:hydrostatic power
Brakes:differential mechanical wet disc
Cab:Folding 2-post ROPS or cab with heat and A/C
Transmissions:9-speed partially synchronized with power shuttle
 9-speed partially synchronzied
Transmission details ...
Photos
No photos of the John Deere 6100D are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:41.7 gal
157.8 L
Hydraulic system:15.3 gal
57.9 L
Front axle:6.9 qts
6.5 L
Front hubs:2.1 qts
2.0 L (each)
Hydraulics
Type:open center
Capacity:15.3 gal
57.9 L
Pressure:2830 psi
195.1 bar
Valves:2 to 3
Pump flow:17.6 gpm
66.6 lpm
Steering flow:6.9 gpm
26.1 lpm
Tractor hitch
Rear Type:II
Control:mechanical lower link
Rear lift (at 24"/610mm):6,800 lbs
3084 kg
Power Take-off (PTO)
Rear PTO:independent
Clutch:dry disc
Rear RPM:540/1000 (1.375)
Engine RPM:540@2100
1000@2100
Dimensions & Tires
Wheelbase:92.5 inches
234 cm
Weight:7275 to 9170 pounds
Front tire:10.00-16
Rear tire:18.4-34 (2WD)
Full dimensions and tires ...
6100D Serial Numbers
Location:Serial number plate on the right side of the tractor frame, above the front axle.
photo of 6100D serial number

Electrical
Ground:negative
Charging system:alternator
Charging amps:70 (ROPS)
 90 (cab)
Battery CCA:925
Battery volts:12
Battery AH:180
Battery Group:31
