Tractors > CaseIH > Steiger 485

CaseIH Steiger 485 Tests



CaseIH Steiger 485 tractor photo
2008 - 2010
Four-wheel Drive (4WD) tractor
Steiger 480 ↑
Series:Steiger 435 ← Steiger 485 → Steiger 535
Steiger 500 ↓
OCED Tractor Test 1934A
Steiger 485 fuel use from test 610
OCED Tractor Test 1934A
Diesel 16-speed 4WD
September 8 - 11, 2008
Link: OCED Tractor Test 1934A file
PTO performance
Max power:498.35 hp
371.6 kW
Fuel use:26.5 gal/hour
100.3 l/hour
Power at rated engine speed:443.69 hp
330.9 kW
Fuel use:25.1 gal/hour
95.0 l/hour
Drawbar performance
Max power:400.38 hp
298.6 kW
Fuel use:24.7 gal/hour
93.5 l/hour
Gear 6 used for power test.
Max pull:43,815 lbs
19874 kg
Gear 3 used for pull test.
