Kubota BX1850


Kubota BX1850 tractor photo
2006 - 2008
BX50 Series
Compact Utility tractor
Series map:
BX1850
BX2350
18.0hp
23.0hp
Production
ManufacturerKubota
Compact Utility tractor
Original price was $8,257 in 2009
Kubota BX1850 Engine
Kubota 0.7L 3-cyl diesel
Engine details ...
Kubota BX1850 Power
Engine18 hp
13.4 kW
PTO (claimed)13.7 hp
10.2 kW
Mechanical
Four-wheel drive
Power steering
Wet disc brakes
Two-post fixed ROPS. Optional canopy.
Capacity
Fuel6.6 gal
25.0 L
Hydraulic system3.1 gal
11.7 L
Hydraulics
Typeopen center
Capacity3.1 gal
11.7 L
Total flow6.3 gpm
23.8 lpm
Tractor hitch
Rear TypeI
Rear lift (at ends)992 lbs
449 kg
Rear lift (at 24"/610mm)670 lbs
303 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Mid PTOindependent
Mid PTO Type2500
Dimensions & Tires
Wheelbase52.8 inches
134 cm
Weight1255 lbs
569 kg
Front tire16x7.5-8
Rear tire24x12-12
Full dimensions and tires ...
Kubota BX1850 attachments
48" mid-mount mower deck
54" mid-mount mower deck
60" mid-mount mower deck
front-end loader
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps40
Battery CCA435
Battery volts12
References
BX1850 references literature
BX Diesel Tractor published in 2006, by Kubota
Operator's Manual BX1850 - BX2350 (K2581-7121-2) published in 2005
