John Deere 9230
|
|
| Production | |
| Manufacturer | John Deere |
| Four-wheel Drive (4WD) tractor | |
| Built in Waterloo, Iowa, USA | |
| John Deere 9230 Engine | |
| John Deere 9.0L 6-cyl diesel | |
 Engine details ... |
| John Deere 9230 Transmissions | |
| 24-speed partial power shift | |
| 18-speed full power shift | |
 Transmission details ... |
| John Deere 9230 Power | |
| Engine | 325 hp 242.4 kW |
| PTO (claimed) | 263 hp 196.1 kW |
| Drawbar (tested) | 241.53 hp 180.1 kW |
| PTO (tested) | 312.59 hp 233.1 kW |
 Performance test details ... | |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | hydraulic differential lock optional |
| Steering | hydrostatic power |
| Hydraulic wet discs brakes | |
| Trailer brakes | hydraulic optional |
| CommandView Cab standard with air-conditioning. Optional automatic climate control and leather trim. | |
| Photos | |
 | |
 John Deere 9230 photos... | |
| Capacity | |
| Fuel | 350 gal 1324.8 L |
| Hydraulic system | 27 gal 102.2 L |
| 28 gal (3-point) 106.0 L | |
| 20 gal (high-flow) 75.7 L | |
| 31 gal (high-flow and 3-point) 117.3 L | |
| Hydraulics | |
| Type | closed-center pressure and flow compensating |
| Capacity | 27 gal 102.2 L |
| 28 gal (3-point) 106.0 L | |
| 20 gal (high-flow) 75.7 L | |
| 31 gal (high-flow and 3-point) 117.3 L | |
| Pressure | 2900 psi 200.0 bar |
| Valves | 4 to 6 |
| SCV flow | 30 gpm 113.6 lpm |
| PowrSync Total flow | 44 gpm 166.5 lpm |
| PowerShift Total flow | 48 gpm 181.7 lpm |
| Hi-Flow Total flow | 78 gpm 295.2 lpm |
| Tractor hitch | |
| Rear Type | 4N/3 |
| 4N/4 | |
| Rear lift (at 24"/610mm) | 15,300 lbs 6940 kg |
| Drawbar | Catergory 4 standard with secondary chain support. Optional reinforcement up to 11,000 pounds. Optional 12,000 pounds Catergory 5 drawbar, not available with 3-point hitch or PTO. |
| Power Take-off (PTO) | |
| Rear PTO | independent (optional) |
| Clutch | electro-hydraulic wet disc |
| Rear PTO Type | 1000 (1.75) |
| Dimensions & Tires | |
| Wheelbase | 137.8 inches 350 cm |
| Weight | 33542 to 34510 pounds |
| Front tire | 620/70 |
| Rear tire | 620/70 |
 Full dimensions and tires ... | |
| 9230 Serial Number Location | |
 | |
| Rear-left of tractor hinge frame on early models. Right side of tractor frame, ahead of front axle, on late models. |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 200 |
| Batteries | 2 |
| Battery CCA | 950 |
| Battery volts | 12 |
| References | |
 | |
| New 9030 Series Tractors published in 2007, by John Deere | |
| 9230, 9330, 9430, 9530 and 9630 Tractors (OMAR283034) published in 2009 | |
| 9230, 9330, 9430, 9530 and 9630 Tractors (OMRE325893) published in 2011 |
