John Deere 9230 Tests

John Deere 9230 tractor photo
2007 - 2011
9030 Series
Four-wheel Drive (4WD) tractor
Nebraska Tractor Test 1940
9230 fuel use from test 1940
Nebraska Tractor Test 1940
Diesel 18-speed 4WD
October 1 - 14, 2008
Link: Nebraska Tractor Test 1940 file
PTO performance
Max power:312.59 hp
233.1 kW
Fuel use:17.5 gal/hour
66.2 l/hour
Power at rated engine speed:265.73 hp
198.2 kW
Fuel use:15.6 gal/hour
59.0 l/hour
Power at rated PTO speed:306.82 hp
228.8 kW
Fuel use:17.1 gal/hour
64.7 l/hour
Drawbar performance
Max power:241.53 hp
180.1 kW
Fuel use:17.6 gal/hour
66.6 l/hour
Gear 7 used for power test.
Max pull:34,440 lbs
15621 kg
Gear 1 used for pull test.
