Tractors > John Deere > 6910

John Deere 6910



John Deere 6910 tractor photo
1997 - 2001
6000 TEN Series
Row-Crop tractor
Series map:
6810
6910
93.2kw
104.4kw
Production
ManufacturerJohn Deere
Row-Crop tractor
Built in Mannheim, Baden-Württemberg, Germany
Variants
6910conventional
6910Shigh-speed
John Deere 6910 Engine
John Deere 6.8L 6-cyl diesel
Fuel tank54.7 gal
207.0 L
 66 gal
249.8 L
Engine details ...
John Deere 6910 Transmissions
24-speed
18-speed full power shift
Transmission details ...
John Deere 6910 Power
Engine140 hp
104.4 kW
PTO (claimed)125 hp
93.2 kW
Mechanical
Four-wheel drive
Final drivesplanetary
Differential lockelectro-hydraulic wet disc
Power steering
Hydraulic wet disc brakes
TechCenter cab standard with air-conditioning.
Photos
John Deere 6910, right side.
John Deere 6910 photos...
Hydraulics
Typeclosed-center load sensing
Pressure2900 psi
200.0 bar
Valves4 OptOptional
Pump flow16.6 gpm
62.8 lpm
 25.4 gpmOptOptional
96.1 lpm
Tractor hitch
Rear TypeII/IIIN
Controlelectronic lower-link draft sensing
Rear Armstelescopic link ends
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000
Engine RPM540@1995
 540E@1743
 1000@1995
Front PTOindependent
Clutchelectro-hydraulic wet disc
Front PTO Type1000
Engine RPM1000@1995
Dimensions & Tires
Wheelbase104.3 inches
264 cm
Weight11400 lbs
5171 kg
Front tire16.9R28
Rear tire20.8R38
Full dimensions and tires ...
John Deere 6910 attachments
front-end loader
Attachment details ...
6910 Serial Numbers
Location:Plate located on right side of main tractor frame.
Electrical
Groundnegative
Charging systemalternator
Charging amps90
 115 OptOptional
Battery volts12
Battery AH154
 174 OptOptional
References
6910 references literature
6010 Series Tractors: 6 cylinder 77 kW to 110 kW published in 2002, by John Deere
More than stepless: simply convincing published in 2002, by John Deere
Operator's Manual 6510, 6610, 6810 and 6910 Tractors (OMAL116300) published in 1999
