John Deere 6810


John Deere 6810 tractor photo
1997 - 2001
6000 TEN Series
Row-Crop tractor
Series:661068106910
Production
Manufacturer:John Deere
Type:Row-Crop tractor
John Deere 6810 Power
Engine:125 hp
93.2 kW
PTO (claimed):113 hp
84.3 kW
John Deere 6810 Engine
John Deere 6.8L 6-cyl diesel
Fuel tank:54.7 gal
207.0 L
 66 gal
249.8 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Steering:power
Transmissions:20-speed
 18-speed full power shift
Transmission details ...
Photos
No photos of the John Deere 6810 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:closed-center load sensing
Pressure:2900 psi
200.0 bar
Tractor hitch
Rear Type:II
Rear Arms:telescopic link ends
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000
Engine RPM:540@1995
540E@1743
1000@1995
Front PTO:independent
Front RPM:1000
Engine RPM:1000@1995
Dimensions & Tires
Wheelbase:104.3 inches
264 cm
Weight:11400 lbs
5171 kg
Front tire:420/70R28
Rear tire:520/70R38
Full dimensions and tires ...
6810 Serial Numbers
Location:Plate located on right side of main tractor frame.
Electrical
Ground:negative
Charging system:alternator
Charging amps:90
 115
Battery volts:12
