International Harvester TD-5


International Harvester TD-5 tractor photo
1959 - 1964
Agricultural Crawler tractor
Production
ManufacturerInternational Harvester
Agricultural Crawler tractor
FactoriesMelrose Park, Illinois, USA
 Hamilton, Ontario, Canada
Variants
T-5gasoline
TD-5diesel
International Harvester TD-5 Engine
International Harvester 2.4L 4-cyl diesel
Fuel tank15.9 gal
60.2 L
Engine details ...
International Harvester TD-5 Transmissions
5-speed gear
10-speed two-speed power shift
5-speed shuttle
Transmission details ...
International Harvester TD-5 Power
Drawbar (claimed)30.2 hp
22.5 kW
Belt (claimed)35 hp
26.1 kW
Drawbar (tested)29.61 hp
22.1 kW
PTO (tested)33.25 hp
24.8 kW
Performance test details ...
Mechanical
Drivecrawler
Final drivesbull gear
Open operator station.
Tractor hitch
Rear TypeI OptOptional
Power Take-off (PTO)
Rear PTOlive OptOptional
Rear PTO Type1000 (1.375)
Engine RPM980@2000
Dimensions & Tracks
Weight6500 lbs
2948 kg
10-inch tracks
Full dimensions and tracks ...
TD-5 Serial Numbers
1959501
19601345
19612215

FAQ: How to read a serial number table.
References
TD-5 references literature
Farm Crawlers published in 1960, by International Harvester
