International Harvester T-5


International Harvester T-5 tractor photo
1959 - 1964
Agricultural Crawler tractor
Series map:
T-4
T-5
36.2hp*
40.0hp*
*Estimated engine power for comparison only.
Production
ManufacturerInternational Harvester
Agricultural Crawler tractor
FactoriesMelrose Park, Illinois, USA
 Hamilton, Ontario, Canada
Variants
T-5gasoline
TD-5diesel
International Harvester T-5 Engine
International Harvester 2.2L 4-cyl gasoline
Fuel tank15.9 gal
60.2 L
Engine details ...
International Harvester T-5 Transmissions
5-speed gear
10-speed two-speed power shift
5-speed shuttle
Transmission details ...
International Harvester T-5 Power
Drawbar (claimed)30 hp
22.4 kW
Belt (claimed)36 hp
26.8 kW
Drawbar (tested)28.6 hp
21.3 kW
PTO (tested)36.01 hp
26.9 kW
Performance test details ...
Mechanical
Drivecrawler
Final drivesbull gear
Open operator station.
Tractor hitch
Rear TypeI OptOptional
Power Take-off (PTO)
Rear PTOlive OptOptional
Rear PTO Type1000 (1.375)
Engine RPM980@2000
Dimensions & Tracks
Weight5959 lbs
2703 kg
10-inch tracks
Full dimensions and tracks ...
T-5 Serial Numbers
1959501
19601345
19612215

FAQ: How to read a serial number table.
References
T-5 references literature
Trucks, Tractors and Farm Equipment in Australia published in 1964, by International Harvester
Farm Crawlers published in 1960, by International Harvester
