AGCO ST24A


No photo available
2005 - 2008
ST-A Series
Compact Utility tractor
Iseki built
Series map:
ST22A
ST24A
ST28A
22.5hp
22.5hp
28.4hp
Production
DistributorAGCO
ManufacturerIseki
Compact Utility tractor
Built in Matsuyama, Japan
AGCO ST24A Engine
Iseki 1.1L 3-cyl diesel
Engine details ...
AGCO ST24A Power
Engine (gross)22.5 hp
16.8 kW
PTO (claimed)19 hp
14.2 kW
Mechanical
Four-wheel drive
Differential lockmechanical rear
Power steering
Wet disc brakes
Two-post fixed ROPS.
Photos
No photos of the AGCO ST24A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pump flow5.3 gpm
20.1 lpm
Tractor hitch
Rear TypeI
Rear lift (at ends)1213 lbs
550 kg
Rear lift (at 24"/610mm)882 lbs
400 kg
Power Take-off (PTO)
Rear PTOtransmission (gear)
 independent (hydrostatic)
Rear PTO Type540 (1.375)
Mid PTOindependent OptOptional
Mid PTO Type2000
Dimensions & Tires
Wheelbase59.9 inches
152 cm
Weight1565 lbs
709 kg
Full dimensions and tires ...
AGCO ST24A attachments
60" mid-mount mower deck
front-end loader
backhoe
Attachment details ...
Electrical
Groundnegative
Battery volts12
References
ST24A references literature
ST Series published in 2004, by AGCO*
*Publication contains known errors.
